FEATURES
- 1100W bi-amped design with Class-D & Class A/B technology
- Lightweight, strong ABS chassis
- Speaker Delay Time
- Custom selected woofers and HF drivers
- Punchy bass with clear highs, and warm mids.
- Onboard DSP processor with mode selection
- 6-band graphic EQ
- Speaker time delay
- High-Pass/Low-Pass Filters
- Main volume control
- Designed and engineered in Australia
- Perfect for DJs, bands, and venues
- 2-way high powered active PA speaker
SPECIFICATIONS
| Product number: | REVO15DSP |
|---|---|
| Product type: | PA loudspeaker |
| Type: | Powered 2-Way |
| Low/mid driver dimensions: | 15″ (381mm) |
| HF driver dimensions: | 1.75” (44.5mm) |
| Amplifier: | Class A/B & Class D |
| Dispersion (H x V): | 90° x 60° |
| RMS: | 350W |
| Peak power: | 1100W |
| Frequency response: | 50 Hz – 20 kHz |
| Max. SPL (peak): | 122dB |
| DSP Control: | 8 Selectable Programs (4 User editable) |
| Max Input Level: | 20 dBu |
| Signal to Noise: | 90 dB (A-Weighted) |
| Total Harmonic Distortion (THD): | <0.5% (1kHz -9dB) |
| Controls: | 1 x mic gain, 1x main level, DSP selector mode, power |
| Indicators: | Power, limit |
| Inputs: | 1x XLR (line), 1x ¼” TS Jack (mic) |
| Outputs: | 1x XLR |
| Other Connections: | 1x USB-B port (DSP Connection) |
| Operating voltage: | 110 – 240 V / 50 – 60 Hz, Switching Power Supply |
| Power Connection: | Powercon |
| Cabinet material: | ABS Plastic |
| Dimensions: | 710 x 450 x 370 mm |
| Weight: | 19.6kg |
